Description

Max Length including ramp : 79.98m. Class : ZC. Hull : Double Hull. Navigation Area : Coastal Waters. Operation Area : A1. Gross Tonnage: 1541. Net Tonnage: 863. Speed: 10.20 knots @Design Draft. Endurance : 12 days. Main Engine: X6170ZC490-2, 360kW*2, 1200rpm, WeiChai.

Specifications

Construction

Built Time: 2025, New Build
Built Place: China
Class: ZC
Flag: China

Max Length including ramp: 79.98m
Length Overall (LOA): 67.50m
Breadth: 15.90m
Depth: 3.80m
Laden Draft: 2.800m
Laden Water Displacement: 2578.00t
Ref Cargo Capacity: 1500t
Max Deadweight: Abt 1800t
Hull: Double Hull
Main Deck Thickness: 15+16=31mm, double plate
Gross Tonnage: 1541
Net Tonnage: 863

Equipment

Towing Rope: Brake Load 483kN?277kN, 2PCs, length 180m
Sewage Treatment Plant: WCBM-10, IMO MEPC.227 (64)
Oil Water Separator: CYSC107-0.25

Anchor: 1440kg*2 Hall Anchor; 1020kg*2 Navy Anchor

Engine(s)

Main Engine: X6170ZC490-2, 360kW*2, 1200rpm, WeiChai
Gearbox: HCD400A, 3.96:1, 1000-1800r/min, 2sets
Fuel Tank: 89ton
Speed: 10.20 knots @Design Draft
Endurance : 12d ays

Certification

Navigation Area: Coastal Waters
Operation Area: A1

Disclaimer

The particulars and specifications are supplied by the vendor and not SeaBoats. Such information has not been verified and may be incorrect. Please do not rely on particulars and specifications unless you have verified their accuracy.
