Description

Vessel Type: Chemical Tanker. Hull Type: Double Hull. Builder: Zhoushan Dingheng Shipyard Co., Ltd., China. Flag: China. Port of Registry: Shanghai. Classification Society: CCS (IACS Member). Class Notation: CSA Chemical Tanker, Type 2, Max. Pressure 0.021 MPa, Loading Computer (S, I, D), ESP, CSM. Trading Area: Unrestricted.
Date Launched: 2008 Length: 96.60m (316ft 11.15in) Beam: 15.00m (49ft 2.55in) Draft: 7.40m (24ft 3.34in) Note: Main Engine: 1 × 4-stroke diesel engine Location: China

Specifications

Accommodation

Total Crew: 18 persons
Officers and Crew Nationality: Chinese
Working Language: Chinese (officers English speaking)

Construction

Vessel Type: Chemical Tanker
Hull Type: Double Hull

Length Overall (LOA): 96.60 m
Length Between Perpendiculars (LBP): 90.00 m
Beam: 15.00 m
Depth: 7.40 m
Gross Tonnage (GT): 2,981
Net Tonnage (NT): 1,143

Number of Cargo Tanks: 10
Total Cargo Capacity at 98%: 4,272 m³
Slop Tanks Capacity: 227 m³
Cargo Tank Type: Integral gravity tanks
IMO Chemical Ship Type: Type 2
Maximum Cargo Density: 1.42 t/m³
Cargo Heating: Steam heating coils fitted in all cargo and slop tanks
Maximum Cargo Temperature: 66°C
Vapour Emission Control System (VECS): Fitted and CCS certified
Cargo Pumps: Screw type, electric driven
Cargo Pumps Capacity: Up to 300 m³/h per pump
Maximum Simultaneous Cargo Pumps: 4
Loading Rate per Manifold: Up to 550 m³/h
Cargo Control Room: Fitted
Closed Gauging System: Fitted with independent HL/HHL alarms

Engine(s)

Main Engine: 1 × 4-stroke diesel engine, 2,206 kW at 525 rpm
Auxiliary Engines: 3 × 200 kW
Propeller: Fixed pitch propeller
Bow Thruster: 160 kW
Service Speed: Approximately 11.0 knots (laden), 10.0 knots (ballast)
Fuel Oil: 158.71 m³
Diesel Oil: 70.70 m³

Certification

Year Built: 2008
Builder: Zhoushan Dingheng Shipyard Co., Ltd., China
Flag: China
Port of Registry: Shanghai
Classification Society: CCS (IACS Member)
Class Notation: CSA Chemical Tanker, Type 2, Max. Pressure 0.021 MPa, Loading Computer (S, I, D), ESP, CSM
Trading Area: Unrestricted
INTERTANKO Member: Yes

Last Dry Dock: May 2024, Zhoushan
Next Dry Dock Due: October 2026
Last Special Survey: September 2021
Next Special Survey Due: October 2026

EEXI: Compliant, Rating 22.4 (Class verified)
NOx Compliance: Tier I
Ballast Water Treatment System: Fitted, UV + Filter, IMO and USCG approved
