Brokerage boats for sale in China
NB BUILDING ORDER 2000/3000 T DERRICK PIPELAY BARGE
Flag:Pending
Class:IACS
Navigation area:Offshore
Delivery time:16 months
Builder:China shipyard
Principal Dimensions and Characteristics
Length of all:169.00 m
Beam:46.00 m
Molded Depth:13.50 m
Molded Draft:7.00-9.00 m
Gross tonnage:4100 t
Generators
Main generator:4 x 2,500 kw/440 v/60 Hz
Emergency generator:1 x3 15 kw/440 v/60 Hz
Pipelaying Equipment
Pipe diameter: 6 to 60 inches
Tensioners:2 x 100 t
A& R winch:1 x 200 t
Firing line:6 welding stations, 1 repair station
3 coating stations,1anode in...
read more
Initially designed as patrol/interceptor boat, this K-TOUGH Hull based boat is also perfect for ambulance/fire rescue/pilot transit/security/escort//command/VBSS/quick response/surveillance and any other types of military/paramilitary/professional operations that need to deal with rough open seas and hostile environments....
read more
This vessel is near completion and will be available for delivery within 2 months of MOA signing.
LOA 78m x 16m x 5.1m.
Following are all quality components for build.
Bow Thrusters -Rolls-Royce
Main Generator Sets 4 x 910 ekw Caterpillar
Emergency Generator Caterpillar
Electric Propulsion Rolls-Royce
Azimuth Propeller RR
Frequency Convertor System and Transformer Rolls-Royce
MSB & Control Console Rolls-Royce
All Cargo Pumps Engine Room Pumps Ing. Per Gjerdrum A.S.
DP2 & C- Rolls-Royce
Mud Agitator Ing. Per Gjerdrum A.S.
Cargo Control and Monitor System Rolls-Royce
Rem...
read more
7000m3 Trailing Suction Hopper Dredger
Built year:2009
Inspection place:China
Classification:CCS
Principal Dimensions and Characteristics
Length of all: 108.6m
Length of Hull: 98.8m
Beam: 20.6m
Molded Deepth: 8.5m
Design Draft:5.5m
DWT:8800t
Speed: 12.00kn
Dredging depth:30m
Crew:33
Endurance:25days
Main Engine
Shanxi Dieseal Engine Factory
Main Engine type:8DKM-28(Daihatsu)
Power/speed:2500KW 750r/min
Q'ty:2 sets
GearBox
CHONGQING Gearbox Group Co.,Ltd
Type:GWC45/49(starboard/port)
Reduction rate:2.4671:1
Diesel generating set
Manufacutre:Henan Dieseal Engine Factory
Model:TBD60...
read more
1- Overall Length:49.80m
2- Beam/Draft: 7.40m/3.8m
3- G.T/N.T:298/112
4- Hull Material: Steel
5- Fishing Method: Stern Trawling
6- Fuel Tank: 167.66m3
7- F. Water Tank: 42.64m3
9- Main Engine:1x Weichai XCW8200 960kw
10- Aux. Engine: Weichai 2XCCFJ250J 250kw +1X 4105 40kw
11- Fish hold capacity: 150 ton
12- Quick-freeze:20ton/day
13- Accommodation: 20 persons
14- Navigational Equipments: Japan Furuno Ocean Going appropriate Equipments.
15- All fishing electronic equipments.
16- All hydraulic winches, cranes & other fishing equipments.
17- Speed: 10 Knts.
18-Delivery ...
read more
12,000 DWT SELF-PROPELLED DECK BARGE
VESSEL TYPE:DECK BARGE
CLASS : CCS
BUILT:2012 CHINA
EXPECT DELIVERY TIME:SHORTLY
GROSS TONNAGE : 9,814
NET TONNAGE: 5,495
DEAD WEIGHT (SUMMER): 12,000TON
LENGTH OVER ALL (LOA) : 142.00M
BREADTH : 32.00 M
DEPTH : 8.00 M
DESIGN DRAFT: 4.25M
CREW:22 P
DESIGN SPEED: 11.5 KNOT
MAIN ENGINE : (2 UNIT 8320ZCD-8) 2 X2,206 KW (RPM 525)
(ALL DTLS GIVEN IN GOOD FAITH BUT W.O.G)...
read more
Principal Dimensions and Characteristics
Year Built: 2007
Class/Owner nation : "China ZC, Offshore/Coastal, Business Area: A1+A2
Inspection in China"
LOA : 80.70 m
L : 78.00 m
LWL : 79.35 m
MB : 30.00 m
MD : 5.80 m
Design Draft (Full Load): 2.80 m
Displacement (Full Load): 6,330 tonnes
Light Displacement: 3,560 tonnes
GRT/NRT: 4,495 / 1,350
Hull Material: Steel
Deck Material: Steel
No. of Deck Layers: 1
No. of Transverse Compartment Bulkheads: 6
Type of Structure: Frame work in length and breadth
Accommodation: 1...
read more
2500m3 Spilt Barge
Blt:Nov 2010 Taizhou China
Class:ZC
Flag:China
Inspection place:China
L.o.a:84m
Beam:14.75m
Depth:5.3m
Draft:3.7m
Displacement:4178t
DWT:2515T
G.T/N.T:2025/607
M.E:WEICHAI 698kw 1000rpm X 2 sets
Generator:Lanzhou 120kw x 2 sets + 30kw x 1 sets...
read more
300MEN ACCOMMODATION WORK BARGE
Class:ABS
Builder:China shipyard
Delivery time:10 month
LxBxD:113.83x31.70x7.3m
Draft:5.00m
Deckhouse:3.00m approx
Seawater:11,800m3 approx
Freshwater:1,090m3 approx
Fuel oil:1,630m3 approx
Sewage storage:120m3 approx
Dirty Oil tank:50m3 approx
Main deck strength:15 ton/m2
Anchors,tugger winches:ZPMC
Generator sets:Caterpillar
Crane:supply by owner...
read more
New Building Order 87 M PSV
Builder:China
Delivery time:20 months
Class :ABS
Dims : 87.075 x18.80 x 7.40 mtr
Design Draft : 6.05 mtr
GRT : 3,671
Dead weight : 5,145tons
Main engines : 4 x Cummins QSK60-D(M) 1,900 KW
Emergency / harbor engine: 1 x 435 KW
Bow thruster : 1 x Rolls Royce 910 KW
Retractable thruster: 1 x Rolls Royce 800 KW
Stern thruster : 2 x Rolls Royce 2,000 KW
Generators : 4 x ABB 2,282 kVA + 1 x 481 kVA
Capacities : f.o. 817.60 m3, d.w/b.w. 1,782.94 m3, f.w. 494.18 m3,
Deck : 1,000 m², 10 tons / m²
Speed : 14.3 knots
DP : DPII
Accommodation : 5...
read more
