NB BUILDING ORDER 2000/3000 T DERRICK PIPELAY BARGE Flag:Pending Class:IACS Navigation area:Offshore Delivery time:16 months Builder:China shipyard Principal Dimensions and Characteristics Length of all:169.00 m Beam:46.00 m Molded Depth:13.50 m Molded Draft:7.00-9.00 m Gross tonnage:4100 t Generators Main generator:4 x 2,500 kw/440 v/60 Hz Emergency generator:1 x3 15 kw/440 v/60 Hz Pipelaying Equipment Pipe diameter: 6 to 60 inches Tensioners:2 x 100 t A& R winch:1 x 200 t Firing line:6 welding stations, 1 repair station 3 coating stations,1anode in... read more

7000m3 Trailing Suction Hopper Dredger Built year:2009 Inspection place:China Classification:CCS Principal Dimensions and Characteristics Length of all: 108.6m Length of Hull: 98.8m Beam: 20.6m Molded Deepth: 8.5m Design Draft:5.5m DWT:8800t Speed: 12.00kn Dredging depth:30m Crew:33 Endurance:25days Main Engine Shanxi Dieseal Engine Factory Main Engine type:8DKM-28(Daihatsu) Power/speed:2500KW 750r/min Q'ty:2 sets GearBox CHONGQING Gearbox Group Co.,Ltd Type:GWC45/49(starboard/port) Reduction rate:2.4671:1 Diesel generating set Manufacutre:Henan Dieseal Engine Factory Model:TBD60... read more

1- Overall Length:49.80m 2- Beam/Draft: 7.40m/3.8m 3- G.T/N.T:298/112 4- Hull Material: Steel 5- Fishing Method: Stern Trawling 6- Fuel Tank: 167.66m3 7- F. Water Tank: 42.64m3 9- Main Engine:1x Weichai XCW8200 960kw 10- Aux. Engine: Weichai 2XCCFJ250J 250kw +1X 4105 40kw 11- Fish hold capacity: 150 ton 12- Quick-freeze:20ton/day 13- Accommodation: 20 persons 14- Navigational Equipments: Japan Furuno Ocean Going appropriate Equipments. 15- All fishing electronic equipments. 16- All hydraulic winches, cranes & other fishing equipments. 17- Speed: 10 Knts. 18-Delivery ... read more

12,000 DWT SELF-PROPELLED DECK BARGE VESSEL TYPE:DECK BARGE CLASS : CCS BUILT:2012 CHINA EXPECT DELIVERY TIME:SHORTLY GROSS TONNAGE : 9,814 NET TONNAGE: 5,495 DEAD WEIGHT (SUMMER): 12,000TON LENGTH OVER ALL (LOA) : 142.00M BREADTH : 32.00 M DEPTH : 8.00 M DESIGN DRAFT: 4.25M CREW:22 P DESIGN SPEED: 11.5 KNOT MAIN ENGINE : (2 UNIT 8320ZCD-8) 2 X2,206 KW (RPM 525) (ALL DTLS GIVEN IN GOOD FAITH BUT W.O.G)... read more

Principal Dimensions and Characteristics Year Built: 2007 Class/Owner nation : "China ZC, Offshore/Coastal, Business Area: A1+A2 Inspection in China" LOA : 80.70 m L : 78.00 m LWL : 79.35 m MB : 30.00 m MD : 5.80 m Design Draft (Full Load): 2.80 m Displacement (Full Load): 6,330 tonnes Light Displacement: 3,560 tonnes GRT/NRT: 4,495 / 1,350 Hull Material: Steel Deck Material: Steel No. of Deck Layers: 1 No. of Transverse Compartment Bulkheads: 6 Type of Structure: Frame work in length and breadth Accommodation: 1... read more

2500m3 Spilt Barge Blt:Nov 2010 Taizhou China Class:ZC Flag:China Inspection place:China L.o.a:84m Beam:14.75m Depth:5.3m Draft:3.7m Displacement:4178t DWT:2515T G.T/N.T:2025/607 M.E:WEICHAI 698kw 1000rpm X 2 sets Generator:Lanzhou 120kw x 2 sets + 30kw x 1 sets... read more

300MEN ACCOMMODATION WORK BARGE Class:ABS Builder:China shipyard Delivery time:10 month LxBxD:113.83x31.70x7.3m Draft:5.00m Deckhouse:3.00m approx Seawater:11,800m3 approx Freshwater:1,090m3 approx Fuel oil:1,630m3 approx Sewage storage:120m3 approx Dirty Oil tank:50m3 approx Main deck strength:15 ton/m2 Anchors,tugger winches:ZPMC Generator sets:Caterpillar Crane:supply by owner... read more

New Building Order 87 M PSV Builder:China Delivery time:20 months Class :ABS Dims : 87.075 x18.80 x 7.40 mtr Design Draft : 6.05 mtr GRT : 3,671 Dead weight : 5,145tons Main engines : 4 x Cummins QSK60-D(M) 1,900 KW Emergency / harbor engine: 1 x 435 KW Bow thruster : 1 x Rolls Royce 910 KW Retractable thruster: 1 x Rolls Royce 800 KW Stern thruster : 2 x Rolls Royce 2,000 KW Generators : 4 x ABB 2,282 kVA + 1 x 481 kVA Capacities : f.o. 817.60 m3, d.w/b.w. 1,782.94 m3, f.w. 494.18 m3, Deck : 1,000 m², 10 tons / m² Speed : 14.3 knots DP : DPII Accommodation : 5... read more
